The VisionMount MD115 is a full-motion desk mount for monitors up to 30" and 35 lbs. This innovative mount can be attached to the back edge or mounted inside the cable opening of desks up to 2.6" thick without the use of tools. Sanus Systems’ Virtual Axis 3D™ technology enables the mount to tilt and swivel with fluid motion in every direction possible, allowing it to move easily from portrait to landscape view. Independent tensions in the arm and head provide effortless adjustment, and an extension arm extends the monitor up to 15" for easy viewing from nearly every angle. Features include adjustable height and a wire management channel to keep cables concealed and organized. The MD115 includes small and large VESA monitor brackets to support VESA 75 x 75, 100 x 100, 200 x 100 and 200 x 200 patterns.

Features:

• Adjustable height allows for perfect positioning
• Innovative clamp attaches to edge of desk or cable hole
• Features a hinged arm for added range of motion
• Lateral roll adjustment ensures TV is perfectly level after hanging
• Large VESA TV brackets fits 200 x 200, 200 x 100 and 100 x 100; small VESA TV bracket fits 100 x 100 and 75 x 75
• Cup-shaped faceplate design allows effortless, fluid motion in every direction possible without the use of tools

Product Specifications
Product Width:	11.25" / 28.58 cm
Product Height:	18.25" / 46.36 cm
Product Depth Min:	6.75" / 17.15 cm
Product Depth Max:	18.50" / 46.99 cm
Product Type Specifications
Maximum TV Weight:	35.00 lb / 15.91 kg
Mounting Pattern:	VESA 100 x 100 VESA 200 x 100 VESA 75 x 75 VESA 100 x 200 VESA 200 x 200
Tilt:	15.00° / - 15.00°
Swivel:	90.00° / - 90.00°
Pan:	90.00° / - 90.00°
Roll:	180.00° / - 180.00°
